HotBox™ EXA

SKU:

123530

314.99

  • RGBAW+UV color mixing via 7x 15W 6-in-1 LEDs
  • Variable electronic dimming & strobe
  • 5 user-selectable 32-bit dimming curves
  • Built-in color & chase macros via DMX
  • Built-in automated programs via master/slave
  • Built-in sound active programs
  • Color mixing ability in standalone mode
  • Rugged and well-built (It hits the gym regularly)
  • Super-quiet variable-speed internal fan cooling
  • RGBAW+UV color mixing via 7x 15W 6-in-1 LEDs
  • Variable electronic dimming & strobe
  • 5 user-selectable 32-bit dimming curves
  • Built-in color & chase macros via DMX
  • Built-in automated programs via master/slave
  • Built-in sound active programs
  • Color mixing ability in standalone mode
  • Rugged and well-built (It hits the gym regularly)
  • Super-quiet variable-speed internal fan cooling

Finish

Options

No items found.

Endless Color Mixing + UV

Set the stage ablaze with engless 6-in-1 RGBAW + ultraviolet color mixing. Add a dash of UV for an eerie hue, or go full on UV to enter psychedelic bliss.

Compact & Sturdy

Features a rock-solid aluminum casing with dual hanging brackets, all wrapped up in a cute little package that weighs just 3.5 pounds and is only 4 x 5 x 5 inches (7.25 inches tall including the brackets.)

2 Year - Extendable Warranty
2 Year - Extendable Warranty

Tech Specs

HotBox EXA fixtures offer 7x 15W 6-in-1 RGBAW+UV LEDs, advanced electronics, and a rock-solid aluminum casing with dual hanging brackets, all wrapped up in a cute little package. It weighs in at just 3.5 pounds and is only 4 x 5 x 5 inches (7.25 inches tall including the brackets.)

It puts out a ton of light, and its user selectable 3/6/8/10 or 11 DMX channel modes allow them to work great with any type of controller. It offers RGBAW+UV color mixing, multiple built-in programs, flicker-free 32-bit dimming, and even easy HSV color mixing ability in 3-channel DMX mode.

Certifications

ETL, RoHS, CE

Optical

Light source: 7x 15W 6-in-1 LEDs 100,000 hours

Beam Angle: 25 degree optics standard, 26 degree beam, 30 degree field

Luminous Intensity: 2,346 Lux @ 2.5M, 534 Lux @ 5M

Control

Protocol: USITT DMX-512

DMX Channels: 3/6/8/10/11

Input: 3-pin XLR Male

Output: 3-pin XLR Female

Operating Modes: Standalone, M/S, Sound Active, Color Preset

Movement
Power & Current

Operating Voltage: 100-264VAC, 47-63 Hz

Fuse: 2A 250V

Power Consumption: 73W, 1.01A, PF: .62

Dimensions

5" x 4" x 5"

3.5

lbs

General Specs
Connectors
Hang Time

/10

Density

/10

Rigging & Application
Tech Specs
Wireless Info
In the Box

Downloads & Manuals

Connect with
an expert

Ready to set the stage with unforgettable lighting? Get in touch to explore our LED lighting solutions.
