G-Max™ 150

SKU:

123517

1599.99

  • Single 150-watt white LED light source
  • 16-bit smooth pan/tilt resolution
  • Pan: 540° Tilt: 270° with 3-phase motors
  • Automatic pan/tilt position correction
  • User selectable 21/23/24-channel DMX modes
  • 7 colors + open color wheel with half-colors
  • 2 gobo wheels, 1 static/1 rotating both with 7 gobos + open
  • 3/8-facet dual prism with variable speed and direction
  • 0-100% linear LED dimmer
  • Extremely silent cooling fans
  • 3-pin and 5-pin male/female input and outputs
  • powerCON® compatible AC power In/Out connectors
  • Single 150-watt white LED light source
  • 16-bit smooth pan/tilt resolution
  • Pan: 540° Tilt: 270° with 3-phase motors
  • Automatic pan/tilt position correction
  • User selectable 21/23/24-channel DMX modes
  • 7 colors + open color wheel with half-colors
  • 2 gobo wheels, 1 static/1 rotating both with 7 gobos + open
  • 3/8-facet dual prism with variable speed and direction
  • 0-100% linear LED dimmer
  • Extremely silent cooling fans
  • 3-pin and 5-pin male/female input and outputs
  • powerCON® compatible AC power In/Out connectors

Options

No items found.

Tech Specs

Brighter, Faster, Stronger, Longer

With an eyeball-ripping 150W LED light source and a bag filled with goodies, G-Max 150 is built to impress. Gobos? How about 2 wheels, each with 7 gobos, including 7 rotating, indexing and interchangeable. Glass? You bet! We've got 4 installed and ready to rock. We'll even throw two extra gobos - so you can change things up when you're feeling saucy.

Customization Station

Wanna break things up a little? Try the 3/8-facet rotating, indexable prism, add the frost filter for a subtle glow, or use its smooth, multi-mode iris. It also offers max speed and performance with 3-phase steppers for 540° pan in 2.2 seconds, and 270° tilt in under 1.2 seconds, and that's silent speed. Its speed-sensitive fans are as quiet as they come.

Certifications

Optical

Light source: 150W white LED

Beam angle: 15 degree

Gobo size: 24.8mm outer, 17.5mm inner

Control

Protocol: USITT DMX-512

DMX Channels: 21/23/24

Operating modes: standalone, master/slave, sound active

3-pin DMX input/output

LCD 4-button control panel

Movement

Pan: 540 degree

Tilt: 270 degree

Power & Current

Operating voltage: 90-260VAC, 50-60Hz

Power consumption: 266W, 2.28A, PF:.99

Dimensions

18.9" x 10.2" x 15"

33

lbs

General Specs

Luminous intensity:

129,313 Lux @ 1M, 45,760 Lux @ 2M, 21,577 Lux @ 3M, 12,158 Lux @ 4M, 7,926 Lux @ 5M
